CAN/CAN FD Host Communication ModulesExact model
BL441B
BL441B is listed in the CAN/CAN FD Host Communication Modules range for robot integration and engineering evaluation. Key specifications: Product type ARM edge computing gateway / industrial controller; Processor Rockchip RK3576J / RK3576. Confirm the final configuration, application fit, availability, and delivery terms through a quotation request.
Specifications
- Product type
- ARM edge computing gateway / industrial controller
- Processor
- Rockchip RK3576J / RK3576
- CPU architecture
- 4 x Cortex-A72 + 4 x Cortex-A53 + 1 x Cortex-M0
- NPU performance
- 6 TOPS
- Memory options
- 2 / 4 / 8 GB LPDDR4X
- Storage options
- 16 / 32 / 64 GB eMMC
- Ethernet
- 2 x 10/100/1000M RJ45
- USB
- 2 x USB 3.2 host, up to 5 Gbps
- HDMI
- Not included on BL441 host variants
- Wireless expansion
- Mini PCIe for optional Bluetooth, Wi-Fi, 4G, or 5G; Nano SIM slot
- Operating-system options
- Linux 6.1.75, Linux-RT 6.1.75, Ubuntu 22.04, Debian 11, or Android 13
- Development stack
- Qt 5.15.11, Node-RED, Docker, Python, C#, MySQL, and SQLite
- Real-time software
- Linux-RT 6.1.75 option; project determinism requires validation
- Power input
- 9-36 VDC
- Input protection
- Reverse-polarity and overcurrent protection
- Temperature range
- Industrial SOM -40 to 85 °C; commercial SOM 0 to 80 °C
- Ingress protection
- IP30
- Mounting
- DIN35 rail or wall mounting
- Enclosure material
- Aluminum alloy and stainless steel
- Complete order code
- Host, SOM, X/Y I/O boards, wireless suffix, and OS image confirmed during RFQ
- X-series I/O slot
- 1 x 20-pin X-series slot
- Y-series I/O slots
- 2 x Y-series slots
- Dimensions
- 48 x 83 x 110 mm
InventoryRFQ available
RFQ availableRequest a Quote
Unit pricing remains unpublished until commercial verification is complete.
