Frameless BLDC/PMSM MotorsExact model
U11544
U11544 is listed in the Frameless BLDC/PMSM Motors range for robot integration and engineering evaluation. Key specifications: Outside diameter 115 mm; Inside diameter 74 mm. Confirm the final configuration, application fit, availability, and delivery terms through a quotation request.
Specifications
- Outside diameter
- 115 mm
- Inside diameter
- 74 mm
- Overall height (L3)
- 44.1 mm
- Voltage
- 48 VDC
- Rated output power
- 1597 W
- Rated torque
- 6.1 N.m
- Maximum torque
- 18 N.m
- Rated current
- 41 A
- Maximum current
- 120 A
- Rated speed
- 2000 rpm
- Maximum speed
- 3200 rpm
- Torque constant
- 0.148 N.m/A
- Rotor inertia
- 5.764 kg.cm2
- Back EMF constant
- 9.8 V/Krpm
- Line resistance at 20 C
- 0.027 ohm
- Line inductance
- 0.047 mH
- Pole pairs (2P)
- 11
InventoryRFQ available
RFQ availableRequest a Quote
Unit pricing remains unpublished until commercial verification is complete.
