Frameless BLDC/PMSM MotorsExact model
U2523
U2523 is listed in the Frameless BLDC/PMSM Motors range for robot integration and engineering evaluation. Key specifications: Outside diameter 25 mm; Inside diameter 11.6 mm. Confirm the final configuration, application fit, availability, and delivery terms through a quotation request.
Specifications
- Outside diameter
- 25 mm
- Inside diameter
- 11.6 mm
- Overall height (L3)
- 23.7 mm
- Voltage
- 24 VDC
- Rated output power
- 47.1 W
- Rated torque
- 0.075 N.m
- Maximum torque
- 0.225 N.m
- Rated current
- 3 A
- Maximum current
- 9 A
- Rated speed
- 6000 rpm
- Maximum speed
- 8000 rpm
- Torque constant
- 0.025 N.m/A
- Rotor inertia
- 0.006 kg.cm2
- Back EMF constant
- 1.95 V/Krpm
- Line resistance at 20 C
- 0.95 ohm
- Line inductance
- 0.2 mH
- Pole pairs (2P)
- 7
InventoryRFQ available
RFQ availableRequest a Quote
Unit pricing remains unpublished until commercial verification is complete.
