Frameless BLDC/PMSM MotorsExact model
U3834
U3834 is listed in the Frameless BLDC/PMSM Motors range for robot integration and engineering evaluation. Key specifications: Outside diameter 38 mm; Inside diameter 18 mm. Confirm the final configuration, application fit, availability, and delivery terms through a quotation request.
Specifications
- Outside diameter
- 38 mm
- Inside diameter
- 18 mm
- Overall height (L3)
- 34.5 mm
- Voltage
- 48 VDC
- Rated output power
- 128 W
- Rated torque
- 0.35 N.m
- Maximum torque
- 1.05 N.m
- Rated current
- 4.4 A
- Maximum current
- 13.2 A
- Rated speed
- 3500 rpm
- No-load speed
- 4500 rpm
- Torque constant
- 0.079 N.m/A
- Rotor inertia
- 0.053 kg.cm2
- Back EMF constant
- 7.5 V/Krpm
- Line resistance at 20 C
- 1.12 ohm
- Line inductance
- 0.9 mH
- Pole pairs (2P)
- 7
InventoryRFQ available
RFQ availableRequest a Quote
Unit pricing remains unpublished until commercial verification is complete.
