Frameless BLDC/PMSM MotorsExact model
U6818
U6818 is listed in the Frameless BLDC/PMSM Motors range for robot integration and engineering evaluation. Key specifications: Outside diameter 68 mm; Inside diameter 40 mm. Confirm the final configuration, application fit, availability, and delivery terms through a quotation request.
Specifications
- Outside diameter
- 68 mm
- Inside diameter
- 40 mm
- Overall height (L3)
- 18.6 mm
- Voltage
- 48 VDC
- Rated output power
- 204 W
- Rated torque
- 0.65 N.m
- Maximum torque
- 1.95 N.m
- Rated current
- 6.3 A
- Maximum current
- 18.9 A
- Rated speed
- 3000 rpm
- No-load speed
- 4500 rpm
- Torque constant
- 0.103 N.m/A
- Rotor inertia
- 0.262 kg.cm2
- Back EMF constant
- 7.5 V/Krpm
- Line resistance at 20 C
- 0.46 ohm
- Line inductance
- 0.57 mH
- Pole pairs (2P)
- 10
